PLANERS

Models

PL 40.25 SG

Intended for mounting on front loaders and skid steer loaders. Designed to remove layers of asphalt or cement under the guard rail. Adjustable milling depth. Available in version with conveyor belt for removing material from trench. Interchangeable milling drums in different widths available on request.

Standard drum width	Depth	Required Oil Flow
350 mm	0-150 mm	75-140 l/min
14 inch	0-6 inch	18-38 gpm

Simex does not accept responsibility or liability for the information provided. Technical modifications may vary without prior notice.These are the standard features, for custom solutions contact us. Request For More Information

PL 40.25 RAIL

Studied for creating one or two small trenches at sides of rail tracks to be filled later with sound-insulating material. Fitted with two guide wheels positioned at front and rear of milling disks that run on the rail to guarantee maximum precision. Wheels available in different forms and sections for different rail profiles. Interchangeable milling disks in different widths available on request.

Standard drum width	Depth	Required Oil Flow
30-40-50-60 mm	0-70 mm	75-115 l/min
1,2-1,6-2-2,4 inch	0-2,75 inch	20-30 gpm

Simex does not accept responsibility or liability for the information provided. Technical modifications may vary without prior notice.These are the standard features, for custom solutions contact us. Request For More Information
